Saddle Clamp Manufacturer,Supplier and Exporter in India
Product Code : EL-WS-10483
Written by Palak Mall, Senior Content Writer · reviewed by Arvind Kumar, Lab Equipment Specialist, 12+ years in laboratory supply · updated 17 October 2026
The Saddle Clamp is a clamp-on connector that takes a single ½ inch female threaded outlet off a 110 mm HDPE pipe, so a galvanized iron branch can be added to a plastic main. It is reinforced, high impact strength polypropylene, UV stabilised, rated at 10 bar at 20°C over a 0 to 50°C range, and is one of the HDPE fittings in Water and Sanitation.
What is specified
| Detail | Figure listed |
|---|---|
| Type | Clamp saddle, single middle outlet |
| Main pipe | HDPE, 110 mm outside diameter |
| Outlet | Female threaded for GI pipe, ½ inch |
| Material | Reinforced, high impact strength polypropylene, UV stabilised |
| Pressure | 10 bar at 20°C |
| Temperature | 0 to 50°C |
A branch without cutting the main
A saddle clamps around the outside of an existing pipe and connects through a hole drilled in its wall, so a service connection can be added without cutting the main and fitting a tee. Where the branch is full size, the Equal Tee Compression Fittings is the alternative at 110 mm.
Questions buyers ask
What thread is the outlet?
Female threaded, for ½ inch galvanized iron pipe.
What pipe does it clamp to?
HDPE pipe of 110 mm outside diameter.
Request a quotation
Send the number of service connections planned through the contact page.
