Optical Square Model Manufacturer,Supplier and Exporter in India
Product Code : SCL-ELE-12080
The Optical Square
Precision Model is a technical geodetic instrument engineered for the empirical
study of perpendicularity, reflective geometry, and right-angle offsets.
Designed for Secondary and Vocational TVET Mathematics Laboratories, it
facilitates the visualization of pentaprism physics and coordinate geometry
under ASTM pedagogical standards. This ISO-compliant system is ruggedized for
high-frequency instructional use in rigorous laboratory environments.
Technical Specifications
|
Tender Specification |
OEM Technical Detail |
|
Material Grade |
Ruggedized Impact-Resistant
Polymer / Machined Metal Housing |
|
Optical Component |
Internal Mirror/Prism
Configured at 45° to Incident Light |
|
Operational Interface |
Precision-Aligned Sight
Apertures for 90° Offset Acquisition |
|
Dimensions |
Standardized Institutional
Laboratory Scale |
Key Pedagogical Outcomes
·
Calibrated
45-Degree Internal Reflectors: Allows students to synthesize the relationship between incident
angles and reflective offsets (2 * 45° = 90°), supporting in "Geometric
Synthesis."
·
Precision
Sight Apertures: Facilitates the
empirical derivation of perpendicular offsets in field survey modeling,
supporting "Applied Trigonometry and Surveying."
·
Ruggedized
Housing: Ensures optical
alignment and mechanical stability during high-frequency manipulation,
reinforcing "Technical Accuracy and Instrument Calibration."
·
Integrated
Mounting Interface: Enables stable
deployment on laboratory workstations for the physical construction of
orthogonal planes, reinforcing "Euclidean Geometric Foundations."
International Logistics & Compliance
To maintain the
mechanical alignment and optical surface integrity during transcontinental
maritime transit, all units are secured in high-density anti-vibration primary
packaging and consolidated in export-grade seaworthy crating (ISPM-15
compliant). International procurement documentation includes the Manufacturer’s
Authorization Form (MAF), Certificate of Conformance (CoC), and User Manuals in
English. The instrument features a tropicalized design, batch-tested for
operational stability in environments reaching 45°C and 90% Humidity to ensure
zero material warping or mirror delamination in extreme climates.
